Peanut Oil Machine

Peanut Screw Oil Press

The oil press is an advanced screw type oil processing equipment. It is widely used in pressing oil from vegetable oil seeds, like peanut, soybean, rapeseed, sunflower seed, sesame, cottonseed, rapeseeds, palm seeds and other nuts and seeds with high oil yield, high working efficiency and simple operation.



Oil crops that can be pressed with oil press:

Unlike the custom-made oil press that can only be used for pressing specific seeds, our new type oil press has wider application. It can be used to press many types of oil from various seeds and nuts, you can just make the oil you like at home easily!



Screw oil press, also known as oil seed expeller, is the essential part of the entire oil mill plant. Our screw oil press is an integrated type oil pressing equipment. It combines the vacuum filter, heater and electric control cabinet. It is widely used for processing sesame, groundnut, soybean, walnut, rapeseed and other oil plants. The oil press is quite popular among small oil mill and individual economic unit.


How Screw Oil Press Works

A screw oil press works by pushing oil seeds through a caged barrel-like cavity. The device uses continuous pressure and friction from the screw drives to compress and moves the oil seeds with the waste products exiting through the other side. The extracted oil flows out through small openings that do not allow the solid seed fiber to pass through. After that, the pressed seeds or waste products are formed into a hardened cake and is removed from the machine through another opening on the other side.





Advantages of our oil press:

1. Labor saving: only 1 or 2 people are needed for the operation that 60% of labor force can be saved.
2. Wide application: more than 30 kinds of oil-bearing crops like peanut, sesame, sesame, rapeseed, sunflower, cottonseed and soybean can be pressed with the oil press.
3. Pure oil: residues can be removed with the vacuum filter to ensure the pure of oil.
4. Small space occupation: 10-20 square meters is enough for the oil mill.



Maintenance of oil press:

1.Check the lubrication condition of the oil press every 50 hours. The oil bottle on the gear box can not be short of oil. Adjust the screw bearing from the screw holes with the squeezing screw shaft. Add butter per shift and prohibit dry grinding.
2. Dust and impurities should be prevented from falling in the lubricating part and check the oil quality of the reducer every year. The operator should replace all the oil when the deterioration of oil is found.
3. The wear parts of oil press should be replaced timely. When the press quality reduces or the discharging of cake or oil is not normal, the operator should remove the screw nut and check the wear condition of the pressing screw, pressing bar and the cake outlet ring.
4. The residual oil press cakes should be cleared after production. Clean the screw oil press and remove the dust and grease on the machine surface.
5. For the long time storage of the screw oil press, the operator should make a complete maintenance and unpick, wash and oil the pressing screw, pressing bar and cake outlet ring, then place them in a dry place.



KMEC is a professional manufacturer to develop, design and produce peanut oil press in China with years of production experience. We provide customers with the first class production equipment and after-sale services. Our oil press has been exported to many countries and regions all over the world. Welcome customers to consult and purchase our products.
